Preiswerter 3″ Etiketten Drucker

PXB37007

Eigenschaften

PXB37007 is a 3 inch direct thermal label printer, the printing speed can up to 152mm/sec. Designed with no losable parts and user-friendly clamshell that allows users to easy open the cover and drop labels into the media bay. Gap auto detection and the black mark sensor is completely adjustable from side to side.

Thermal sensitive resistance, photoelectric sensor
Serial + USB + LAN
Labels peel off, tear off automatically
Memory: DRAM 4M, NV FLASH 4M
Support PDF417, QR Code, Data matrix 2D printing
100 MB Ethernet interface connection, data transfer efficiency

Technische Details

Printing method	Direct thermal
Resolution	203dpi (8dots/mm)
Paper width	20 – 82mm
Paper roll diameter	25mm (Min) for internal, 100mm (Max) for external
Printing length (Max.)	1000mm
Paper thickness	0.06 – 0.19mm
Printing speed	Min: 50.8mm/s Max: 152mm/s
Print head temperature sensor	Thermal sensitive resistance
Linear Bar Codes	CODE128, EAN128, ITF, CODE39, CODE93, EAN13, EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR, POSTNET, UPC-A, UPCA+2, UPCA+5, UPC-E, UPCE+2, UPC-E+5, CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14
Print head position sensor	Micro switch
Media type	Paper roll, sticker, label fold, etc.
2-Dimensional	PDF417, QR CODE, Data Matrix
Paper off type	Tear off or Peel off
Internal font	FONT 0 to FONT 8; Commonly used in single-byte fonts
Enlargement & rotation	1 to10 times enlargement in both directions; 0°, 90°, 180°, 270°, 360° rotation
Gross weight	1.50 kg
Dimension	231(D) x 163(W) x 150.7(H) mm
Work	5~45℃, 20~80%RH
Storage	-40~55℃, ≤93%RH (40℃)
Drivers	Win XP / Win Vista / Win 7 / Win 8 / Win 10 / Android / IOS
Input	24VDC, 2.5A
Paper exists detection	Photoeletric sensor
Interface	Serial+ USB + LAN
Memory	DRAM: 4M; FLASH: 4M
Image	Monochromatic PCX, BMP image files can be load to FLASH, DRAM
